Endless 78102 Baffle Linear Light

SKU: LUL78102-Baffle

Endless 78102 Baffle Linear Light

SKU: LUL78102-Baffle
Regular price $328.00
/
Dimension
TYPE
Colour Temperature
  • Customizable
  • Worldwide shipping
  • Secure payments

Our Endless 78102 range refers to the specifications of these modern linear lights - 62mm x 82mm. can be configured with direct or direct/indirect illumination and can be surface mounted or suspended for flexibility in residential and commercial applications. Through the modular connect system, a continuous length of 50m can be created.
The Endless 78102 Opal Prismatic Linear delivers on a simple premise – extensibility in configuration and seamlessness in installation. The sizes and lengths of the Endless 78102 Opal Prismatic Linear has been designed to meet even the most rigorous project requirements. The correlating accessories provide infinite extensibility for projects small and large.
Surface mounted or suspended 78102 linear profiles can be paired with a baffle option to further reduce glare

Tax included. Shipping calculated at checkout.
Enquiry now
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light
Endless 78102 Baffle Linear Light

Product Specification

TYPE: Surface, suspended or recessed
Profile Options:Direct. Direct/Indirect
Diffuser Options:Baffle
Size:62x82mm
Dimension:575MM,855MM,1135MM,1415MM,1695MM,1975MM,2255mm
Direct Illumination:15W,22W,30W,38W,45W,52W,60W
Indirect  Illumination:7W,11W,15W,19W,22W,26W,30W
Lumens:Up to 101lm/w
Power Factor>0.90
Dimmable Option:Non-Dimmable ,1-10V Dimming, TRIDONIC DALI Dimmable
Voltage:240V
Beam Angle:Baffle98°
Colour Deviation| SDCM≤3
UGR (Unified Glare Rating) <22 (Opal), <19 (Prismatic/Baffle)
IP 20 or 40
Colour Temperature:2700K,3000K,4000K
LED Chips:SAMSUNG CRI82
Average Rated Life:50,000 hours
Material:Aluminum alloy 6063
Color:Textured Black, Textured White,or Custom colour
Certifications:SAA,C-tick, CE,RoHS
